※Main Characteristics
1.machine speed and glue feeing speed are controlled manually, and tracked automatically and synchronously. 2.Intelligent PID temperature controlling system,the tolerance is within 1 ℃
3.All active rollers and passive rollers are adjusted by high precision balanceable device.And the logicalinstallingtechnology makes sure the machine runs stably, low noise, laminating materials no-crinkling.
4.High precision alloy steel coating die and high exactitude gear pump ensures high quality coating.
※Range of Application
This equipment mainly produces butyl adhesive tape,
waterproof paste, leak-proof tape, anticorrosive adhesive tape, butyl bond adhesive tape, also can produce PVC,
epdm, self-adhesive waterproof rolling material.Mainly used in waterproof, construction,leakage, sealing, wind power
industry, battery industry.
※Technical Parameters
Model | JYJ |
Coating Width | 400-3000mm |
Coating Weigh | 100-6000g/m2 |
Coating Speed | 1-50m/min |
Unwind Diameter | 1000mm |
Rewind Diameter | 700mm |
Correction Device | 1sets |
Length | 7500mm |
Height | 1600mm |
