PUR TANK
JIAYUAN
PUR TANK
Adopting an advanced pressure plate melting structure, this equipment achieves controlled, high-efficiency adhesive melting while minimizing adhesive exposure to air, effectively blocking moisture contamination and premature curing. As a core Industrial PUR Glue Melting System, it delivers stable, continuous PUR adhesive supply for coating and laminating equipment via fully automatic operation and precision temperature control, making it the preferred solution for industrial production operators pursuing high bonding strength and long-term reliable performance.
The innovative direct contact melting structure of this Pressure Plate PUR Glue Melter greatly improves heat transfer efficiency, reduces adhesive carbonization, and ensures consistent bonding performance. The nearly zero-residue design maximizes adhesive utilization, cuts down adhesive waste, and lowers long-term production costs for manufacturing enterprises.
Tailored for moisture-curing PUR formulations, this Moisture Reactive PUR Hot Melt Equipment strictly controls air contact during the entire melting and supply process, effectively preventing premature curing and maintaining the integrity and bonding strength of the adhesive, even during long-term continuous production.
Equipped with a PLC control system, this PUR Hot Melt Adhesive Supply Machine realizes precise pressure and temperature regulation. Multi-zone independent heating ensures uniform adhesive viscosity, avoids overheating and material degradation, and supports unattended continuous production, greatly improving production efficiency.
Made of high-temperature resistant, heavy-duty industrial components, the equipment is designed for long-term stable operation in harsh industrial environments. It offers multiple tank sizes and output capacities, and can be customized to match different production needs, with excellent compatibility with various coating, laminating and dispensing production lines.
Model | Capacity | Melting Speed | Tank Diameter |
PUR5 | 5gal | 12kg/h | 280/286mm |
PUR55 | 55gal | 50kg/h | 567/571mm |
JYP-015 | 20kg | 15kg/h | - |
JYP-045 | 56kg | 45kg/h | - |
JYP-130 | 200kg | 130kg/h | - |
JYP-200 | 300kg | 200kg/h | - |
JYP-500 | 1000kg | 500kg/h | - |
*Note: Standard version output up to 285 lbs per hour, high-output version up to 475 lbs per hour. | |||
This PUR Hot Melt Adhesive Machine for Coating and Laminating is widely used across multiple industrial sectors, including woodworking, edge banding, profile wrapping, furniture manufacturing, panel lamination, automotive interiors, textile bonding, and industrial composite production. It is especially suitable for production links that require high-strength, durable bonding, and can provide stable adhesive supply for various automated production lines, meeting the strict production requirements of large-scale manufacturing enterprises.
The standard output version can dispense up to 285 lbs of adhesive per hour, while the high-output version can achieve a melting and dispensing capacity of up to 475 lbs per hour, with multiple models available to match different output demands.
The machine adopts a closed pressure plate melting structure, which minimizes the contact between the adhesive and air during the entire melting and supply process, effectively blocking moisture contamination in the air and avoiding premature curing of the moisture-reactive PUR adhesive.
Yes. This equipment is designed with high compatibility, can be seamlessly matched with various coating, laminating, and dispensing systems, and supports customized configuration to adapt to the layout and process requirements of your existing production lines.
As a professional manufacturer of industrial adhesive equipment, JIAYUAN has many years of R&D and production experience in the field of hot melt adhesive equipment. Our Automatic PUR Adhesive Heating Machine series is manufactured in strict accordance with international industrial standards, with strict quality inspection before delivery. We provide comprehensive pre-sales consultation, customized solution design, and complete after-sales support, including technical guidance, spare parts supply, and online troubleshooting, to provide full-cycle technical support for your production, and help industrial business purchasers achieve stable and efficient production.
